How to Find Arc Length of a Vector Valued Function

To find the arc length of a vector valued function, integrate the magnitude of its derivative over the given interval:

L = ∫ₐᵇ ‖r′(t)‖ dt

That single formula is the entire method. If r(t) = ⟨x(t), y(t), z(t)⟩ traces a smooth curve as t runs from a to b, then ‖r′(t)‖ = √(x′(t)² + y′(t)² + z′(t)²) is the speed at each instant, and integrating speed over time gives total distance traveled. The idea is the same whether the curve lives in two dimensions or three — you are just adding up infinitely many tiny straight-line pieces.

The rest of the work is almost always calculus rather than new theory: differentiating correctly, simplifying the square root if you can, and evaluating the resulting integral.

The Formula and Where It Comes From

Imagine approximating a curve with a chain of straight segments between nearby points. Each segment’s length comes from the distance formula, and the sum of all those lengths approximates the curve. Adding more points makes the chain hug the curve more closely, and the least upper bound of those sums — when it exists — is the curve’s length. Curves with finite length are called rectifiable, and the process is sometimes called curve rectification (Wikipedia).

Turning that limit into a usable integral is a short step. Over a tiny time interval dt, the displacement is approximately r′(t) dt, so the distance covered is ‖r′(t)‖ dt. Summing over the interval produces the integral above. In two dimensions the formula reduces to the familiar plane-curve case:

L = ∫ₐᵇ √(x′(t)² + y′(t)²) dt

Nothing changes in three dimensions except the extra z′(t)² term under the root. Unlike the polygonal approximation, you never have to take a limit by hand — the derivative handles it (MIT OpenCourseWare).

A Step-by-Step Procedure

Work through these steps in order and most problems become mechanical:

• Find r′(t). Differentiate each component separately.
• Compute ‖r′(t)‖. Square each component of the derivative, add, then take the square root.
• Simplify before integrating. If the expression under the root factors nicely, the integral may collapse into something elementary.
• Set up the definite integral with the interval endpoints from the problem.
• Evaluate and sanity-check the magnitude of your answer against the geometry of the curve.

Step three is where problems are won or lost. Many textbook curves are chosen so that the speed simplifies to a constant or a single power of t.

Worked example: a helix

Let r(t) = ⟨2cos t, 2sin t, t⟩ for 0 ≤ t ≤ 2π.

Differentiate: r′(t) = ⟨−2sin t, 2cos t, 1⟩.

Now take the magnitude:

‖r′(t)‖ = √(4sin²t + 4cos²t + 1)

Since sin²t + cos²t = 1, the first two terms combine to 4, leaving:

‖r′(t)‖ = √(4 + 1) = √5

The speed is constant, so the integral is just speed times elapsed time:

L = ∫₀²π √5 dt = 2π√5

Notice how the trigonometric terms vanished. That simplification is typical of circular and helical motion, and it is the reason these curves show up so often in examples (Paul’s Online Math Notes).

Worked example: a parabola

Let r(t) = ⟨t, t²⟩ for 0 ≤ t ≤ 1.

Then r′(t) = ⟨1, 2t⟩, so ‖r′(t)‖ = √(1 + 4t²).

This one does not collapse to a constant. The integral is:

L = ∫₀¹ √(1 + 4t²) dt

Evaluating it requires a substitution or a standard integral table, and the result contains an inverse hyperbolic sine. Not every arc length integral is elementary — some require numerical approximation, and that is expected rather than a sign you made a mistake.

Common Pitfalls and Practical Checks

A few errors account for most lost points on this topic.

Forgetting the square root. The integrand is the magnitude of the derivative, not the derivative itself. Writing ‖r′(t)‖² under the integral is a frequent slip.

Skipping the simplification step. Students often push straight into integration with a messy square root that would have factored cleanly. Try to combine terms using identities before you reach for a technique (Khan Academy).

Confusing the interval with the parameter. The limits a and b are values of t, not of arc length. Substituting the endpoints into r(t) gives two points, and the answer should equal the distance along the curve between them.

Assuming smoothness. The formula assumes r′(t) is continuous and never zero on the interval. If the velocity vanishes at a point, the curve may have a cusp or corner there, and you should split the integral at that point.

A quick sanity check helps too. If r(t) = ⟨t, t⟩ on 0 ≤ t ≤ 1, the true length is √2 ≈ 1.414, and the formula returns exactly that. If your computed answer for a similar curve is wildly larger or smaller, go back and recheck the derivative.

Arc Length in Two Dimensions vs. Three Dimensions

The formula does not care how many components your vector has, but the number of terms under the radical changes the difficulty of the integral in practice. Plane curves carry two terms; space curves carry three. That extra term is the only structural difference between the two cases.

Each row is a case where the speed is constant, so the integral becomes multiplication. The line row is a useful check: the length of a straight segment from the origin to ⟨a, b, c⟩ is √(a² + b² + c²), which matches the formula exactly.

A space curve with a nonconstant speed

Let r(t) = ⟨t, (2/3)t^(3/2), t²⟩ on 0 ≤ t ≤ 3.

Differentiate component by component:

r′(t) = ⟨1, t^(1/2), 2t⟩

Square and add:

‖r′(t)‖ = √(1 + t + 4t²)

This quadratic under the root does not factor into a perfect square, so you would evaluate it with a substitution or numerically. The point of the example is the setup: every component is differentiated independently, and the Pythagorean-style sum absorbs all three directions.

Building Intuition for the Integrand

The quantity ‖r′(t)‖ deserves a second look because it carries physical meaning. If t represents time, then r′(t) is the velocity vector and its magnitude is the speed of the moving point. Arc length is therefore the total distance traveled, which is exactly what integrating speed over a time interval computes. This is why the same formula shows up in physics when a particle moves along a prescribed path.

Two consequences follow directly from that reading:

• Shared curves give shared lengths. Any two parametrizations that trace the same path in the same direction over their respective intervals yield the same total length, even if one moves faster. A circle traced once by r(t) = ⟨cos t, sin t⟩ on 0 ≤ t ≤ 2π and once by s(u) = ⟨cos 2u, sin 2u⟩ on 0 ≤ u ≤ π both have length 2π.
• Speed changes stretch nothing. A particle that speeds up and slows down still covers the same total distance as a constant-speed particle, provided it travels the same path from the same start to the same end.

The integral is a property of the geometric curve, not of the particular parameter used to describe it. The parametrization only decides how quickly you traverse the curve and where your limits land.

Whenever you see sines and cosines with matching coefficients and the same argument, expect them to cancel under the square root. Whenever the coefficients differ, as in ⟨3cos t, 4sin t⟩, the identity does not collapse the same way, and the integral typically resists elementary methods. Learning to spot that difference before you start integrating saves time.

When to Reach for Numerical Evaluation

Not every arc length integral resolves into elementary functions. The parabola example from earlier is a mild case; adding a term like sin t inside the root usually pushes a problem past what substitution can handle. In those situations, a numerical approximation is the standard and acceptable approach.

Two practical signals that a numerical method is the right call:

• The radical contains a sum of terms with different powers of t that will not factor.
• The integrand mixes polynomial and transcendental pieces, such as √(1 + t² + e^(2t)).

The underlying method never changes across all of these cases. You differentiate, take the magnitude, and integrate — the only variable is whether the integral yields to hand techniques or needs assistance. That consistency is what makes arc length one of the more reliable topics in vector calculus.

Key Takeaways

• The arc length of a vector valued function is the integral of the speed: L = ∫ₐᵇ ‖r′(t)‖ dt.
• In components, ‖r′(t)‖ = √(x′(t)² + y′(t)² + z′(t)²); use the two-term version for plane curves.
• Simplify the expression under the square root before integrating — trigonometric identities and factoring often make the integral trivial.
• A constant speed, as in a helix, reduces the problem to speed times elapsed time.
• The endpoints a and b are parameter values, not distances.
• Some integrands have no elementary antiderivative, so numerical evaluation is legitimate.
• The method assumes a smooth curve; split the integral at any cusp or corner.
